Ricoh MP C2504 User Manual

Anti-Condensation Heater (PCDU)
• This option is provided as a service part.
• If you want to install Anti-Condensation Heater (PCDU), electrical parts (1) and heater for PCDU
(2) should be ordered.
Accessory Check
(1) Electrical parts
Description Q’ty Remarks
TAPPING SCREW M3X6 3 Parts Number:
D2386650
Electrical parts set for Scanner and Drum
heater is common between NA/EU
CLAMP 6
HARNESS: SCANNER/PCU 1
PCB: DHB 1
HARNESS :DC: DHB 1
HARNESS :AC: DHB 1
(2) Heater for PCDU
Description Q’ty Remarks
TAPPING SCREW: WASHER M3X8 1 Parts Number:
• NA (120V): D7390116
• EU/AA (220/240V): D7390117
HEATER: PHOTOCONDUCTOR: EU
HEATER: PHOTOCONDUCTOR: NA
1
DECAL HIGHT TEMP 1
2. Installation
108
