Ricoh MP C2504 - Spdf Df3100; Accessory Check

To Next Page

To Previous Page

SPDF DF3100 (D3B0)

Accessory Check

No. Description Q’ty Remarks

1 Attention Decal – Top Cover 1

2 Ferrite Core (L) 1

3 Ferrite Core (S) 1

4 Face-Up Document Decal 1

5 Knob Screw 2

6 Stud Screw 2

7 Screw (3x6) 4

2. Installation

152
