Ricoh MP C2504 - Electrical Parts

To Next Page

To Previous Page

Electrical Parts

Items

MP C2003/C2503

/C2011

MP C6004/C5504/C4504

/C3504/C3004

MP C2004/C2504

SIO Available

Not available

The functions for this old board are included on the

IPU

Human detection

(Proximity sensor)

Not Available

Available

Equipped with the proximity sensor (human detection

sensor).

OPU

1st generation Smart

Operation Panel

2nd generation Smart Operation Panel

7. Detailed Descriptions

1082
