2. Peel the backing paper off the velcro fastener, and attach the antenna on the rear cover
and scanner left cover as shown ( x4).
• Take care to loop it around so that it does not interfere with other options or I/F cables.
3. Turn ON the main power.
4. Check that the system settings list is output, and the option is recognized correctly.
User Tool Settings for IEEE 802.11a/g/n
Go into the User Tools mode and do the procedure below. These settings take effect every time the
machine is powered on.
• IEEE 802.11a/g/n function is disabled while using Ethernet.
1. Press the "User Tools" icon.
2. Press "Machine Features" > "System Settings".
• Select "Interface Settings"> "Network" > "LAN Type". The "LAN Type" (default: Ethernet) must
be set for either Ethernet or wireless LAN.
3. Select "Interface Settings"> "Wireless LAN". Only the wireless LAN options show.
4. Set the "Communication Mode".
5. Enter the "SSID setting". (The setting is case sensitive.)
6. Set the "Ad-hoc Channel". You need this setting when Ad Hoc Mode is selected. The
allowed range for the channel settings may vary for different countries.
• For mainly Europe and Asia
2,412 - 2,462 MHz (1 - 11 channels)
2. Installation
292
