Ricoh MP C2504 - Upper Limit Sensor; Paper End Sensor

To Next Page

To Previous Page

3. Transport sensor [A]

Upper Limit Sensor

1. Paper feed unit (page 564)

2. Upper limit sensor [A]

Paper End Sensor

1. Paper feed unit (page 564)

Paper Feed

573
