Controller SP Tables - SP7000
SP7-XXX (Data Log)
7401 [Total SC]
Stores total SC occurring count.
If the same SC codes are detected continuously and total counter is not increasing, it
only logs once in case of deleting other SC code logs.
7-401-001 SC Counter *CTL [0 to 65535 / 0 / 1/step]
7-401-002 Total SC Counter *CTL [0 to 65535 / 0 / 1/step]
7403 [SC History]
Logs and displays the SC codes detected.
The 10 most recently detected SC Codes are displayed on the screen, and also can
be seen on the SMC (logging) outputs.
• If the same SC codes are detected continuously and total counter is not
increasing, it only logs once in case of deleting other SC code logs.
7-403-001 Latest *CTL [- / - / -]
7-403-002 Latest 1 *CTL
7-403-003 Latest 2 *CTL
7-403-004 Latest 3 *CTL
7-403-005 Latest 4 *CTL
7-403-006 Latest 5 *CTL
7-403-007 Latest 6 *CTL
7-403-008 Latest 7 *CTL
7-403-009 Latest 8 *CTL
7-403-010 Latest 9 *CTL
Controller SP Tables - SP7000
569
