Ricoh MP C2504 - Duplex Unit

To Next Page

To Previous Page

Duplex Unit

No. Description No. Description

1 Duplex entrance motor 5 Bypass pick-up solenoid

2 Right door open/close sensor 6 Bypass / Duplex motor

3 Duplex entrance sensor 7 Duplex exit sensor

4 Duplex guide plate open/close sensor 8 Bypass paper end sensor

7. Detailed Descriptions
