Ricoh MP C2504 - How to Install Firmware Downloaded with Reserve

To Next Page

To Previous Page

• This information will only be displayed if the reserved firmware has already been

downloaded. If not, all the data items are indicated with "-".

How to Install Firmware Downloaded with Reserve

1. Enter the SP mode.

2. Press [Firmware Update].

Firmware Update (Smart Firmware Update)

695
