• If failure, execute SP2-111-004 once more and check the result again.
• Fix the color registration errors, referring to page 654 "Judgment for Type of Color
Registration Error".
Also, results for each color can be checked with SP2-194-010 to 013 (MUSIC Execution
Result: Error Result C, M, Y, K).
1: Completed successfully
6. Exit the SP mode.
SP descriptions
• SP2-111-004 (Forced Line Position Adj. Mode d)
Executes the fine line position adjustment and rough line position adjustment.
• SP2-194-007 (MUSIC Execution Result: Execution Result)
Displays the result code of MUSIC adjustment.
0: Success
1: Failure
• SP2-194-010 to 013 (MUSIC Execution Result: Error Result C,M, Y, K)
Displays the result code of MUSIC adjustment for each color.
0: Not done
1: Completed successfully
2: Cannot detect patterns
3: Fewer lines on the pattern than the target
4: Out of the adjustment range
5 to 9: Not used
Checking the Copy Image with the Test Chart
Make a copy of a test chart and check the output quality.
Paper Settings
Adjusts the side-to-side registration, refer to the “Image Adjustment” > “Registration” section.
1. Enter SP2-109-003.
2. Print out the test pattern (14: Trimmed area) with SP2-109-003.
3. If necessary, adjust the registration for the paper feed tray.
• SP1-002-001 (Side-to-Side Registration: By-pass Tray)
