Ricoh MP C2504 User Manual

SC500 (Engine: Fusing)
SC No. Type Error Name/Error Condition/Major Cause/Solution
SC530-00 D Fusing Exhaust Fan Lock
In the motor ON state, the value of the lock sensor is checked every 0.1
sec.
If a lock signal is not obtained for 50 times consecutively.
• Motor defective
• Connector disconnected
• Harness broken
• IOB defective
• Replace the fusing exhaust fan.
• Reconnect the connector.
• Replace the harness.
• Replace the paper transport IOB.
SC No. Type Error Name/Error Condition/Major Cause/Solution
SC531-01 D Development Intake Fan/Right Lock
SC531-03 D Drive Cooling Fan Lock
In the motor ON state, the value of the lock sensor is checked every 0.1
sec.
If a lock signal is not obtained for 50 times consecutively.
• Motor defective
• Connector disconnected
• Harness broken
• IOB defective
• Replace the development intake fan/right for SC531-01, or drive
cooling fan for SC531-03.
• Reconnect the connector.
• Replace the harness.
• Replace the imaging IOB.
Service Call 501-584
819

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
