Then, the current PM counter value is automatically moved to the PM Counter – Previous
(SP7-906-1 to 10) and is reset to "0".
• SP7-853 (Replace Counter)
Displays the number of times each PM part has been replaced.
• SP7-908 (Previous Unit Counter: Pages (%))
Displays the PM counter of the previous PM Part which was replaced last time.
• SP7-950 (Unit Replacement Date)
Displays the replacement date of each PM unit.
• SP5-990 (SP Print Mode)
Prints the configuration sheets of the system and user settings : SMC.
Make sure to shut down and reboot the machine once before printing the SMC. Otherwise, the
latest settings may not be collected when the SMC is printed.
Preparation before Operation Check
1. Clean the exposure glasses (for DF and book scanning).
2. Enter the user tools mode.
3. Do the "Automatic Color Calibration (ACC)" for the copier mode & printer mode as
follows:
• Print the ACC test pattern (User Tools > Maintenance > ACC > Start).
• Put the printout on the exposure glass.
• Put 10 sheets of white paper on the test chart. This ensures the precise ACC adjustment.
• Close the ARDF or the platen cover.
• Press "Start Scanning" on the LCD. Then, the machine starts the ACC.
4. Exit the User Tools mode, and then enter the SP mode.
5. Perform line adjustment.
SP2-111-004: Forced Line Position Adj. Mode d
The result can be checked with SP2-194-007 (MUSIC Execution Result Execution Result)
(0: Success, 1: Failure).
Also, results for each color can be checked with SP2-194-010 to 013.
6. Exit the SP mode.
SP Descriptions
• SP2-194-007 (MUSIC Execution Result: Execution Result)
PM Parts Settings
393
