Registration Sensor: Lag Jam: Cause Code 057
Target Part/SP No.:Registration Sensor / SP5-803-001
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position
of the referenced sensor.
0 :Paper detected
Execute an INPUT check when there is paper at the position of
the referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.: Bypass/Duplex Motor / SP5-804-071 (Duplex Bypass
Motor:CW:Standard Speed)
Cause verification Problem Judgement
Turn the referenced motor OFF with OUTPUT check Drive sound heard
Turn the referenced motor ON with OUTPUT check Drive sound not heard
Solution:
• Reconnect the connector.
• Replace the motor.
• Replace the Paper Transport IOB.
• Replace the harness.
Target Part/SP No.:Reverse Motor / SP5-804-047 (Inverter Motor:CW:Standard Speed)
Cause verification Problem Judgement
Turn the referenced motor OFF with OUTPUT check Drive sound heard
Turn the referenced motor ON with OUTPUT check Drive sound not heard
Solution:
• Reconnect the connector.
6. Troubleshooting
1024

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
