ARDF DF3090 (D779)

Accessory Check

No. Description Q’ty Remarks

1 ARDF 1

2 Screw 2

3 Knob Screw 2

4 Stud Screw (Small) 1

5 Stud Screw (Large) 1

6 Attention Decal – Top Cover 1

Installation Procedure

• Turn OFF the main power and unplug the power cord from the wall socket. If installing without

turning OFF the main power, an electric shock or a malfunction may occur.

2. Installation
