Ricoh MP C2504 - Bridge Unit BU3070 (D685); Accessory Check; Installation Procedure

Bridge Unit BU3070 (D685)
Accessory Check
No. Description Q’ty
1 Tapping screw- M3 × 8 1
2 Screw - M4 1
3 Knob Screw - M4 1
4 Right Front Bracket 1
5 Upper Left Cover 1
6 Left Front Bracket 1
7 Paper Support Guide 1
8 Driven Roller (Flat) 1
Installation Procedure
• When installing this option, turn OFF the main power and unplug the power cord from the wall
socket. If installing without turning OFF the main power, an electric shock or a malfunction may
occur.
• The bridge unit cannot be used together with the following peripherals:
Bridge Unit BU3070 (D685)
