USB Device Server Option Type M19

(D3BC-28,-29)

Accessory Check

No Items Q’ty Remarks

1 USB Cable 1

2 Interface Board 1

3 Ferrite Core 2

4 Cable Ties 2

• An Ethernet cable is not packed with this option.

2. Installation

276
