Ricoh MP C2504 - Bypass Pick-Up Roller; Bypass Paper Feed Roller; Bypass Separation Roller;Torque Limiter

Bypass Pick-up Roller
1. Open the bypass tray.
2. Bypass pick-up roller [A]
Bypass Paper Feed Roller
1. Bypass paper end sensor unit (page 579)
2. Bypass paper feed roller [A]
Bypass Separation Roller/Torque Limiter
1. Open the right door.
Bypass Tray Unit
581
