5. Forced toner supply (only when newly installing the machine)
This step is required only when the machine is newly installed because there is no toner in the toner
transport route.
When the developer initial setting is successfully completed, the machine stores the calculated Vt as
Vtref. The Vtref is used as a reference the next time the machine performs an initial developer
setting.
SC360-01 through -04 appears if the results of step 3 are as follows:
• The count is equal or exceeds the threshold (6480 [counts]).
• The count does not match the target threshold (5800 – 6380 [counts]) three times
consecutively.
Process Control and MUSIC are forcibly done after developer initial setting when a PCDU is replaced.
MUSIC (Automatic Color Registration Correction)
Correction Timing
The machine creates correction patterns, measures the image position by reading the correction
patterns, and corrects the writing position.
Operative Condition Notes
1
Power switch just turned on, or recovering from the
energy save mode
Mode b or Mode a is done
See notes *1 and *2 below.
2
When printing (when the temperature has changed by a
certain amount since the previous job ended, or when
the number of pages printed becomes more than a set
number)
Mode b is done
3
End of printing (when the temperature has changed by a
certain amount since the previous job ended, or when
the number of pages printed becomes more than a set
number)
Mode b is done
4
Front cover opening/ closing (when the temperature
has changed by a certain amount since the previous job
ended)
Mode b is done
Process Control
