Tray Paper size
Loading number of
sheets
Corresponding paper
thickness
1st paper tray
A4 landscape - A5
landscape
550 sheets 60 to 300 g/m
2
2nd paper tray SRA3 - postcard 550 sheets 60 to 300 g/m
2
Bypass feed tray SRA3 - postcard 100 sheets 60 to 300 g/m
2
Duplex unit SRA3 - A6 portrait Interleave 60 to 169 g/m
2
Tray Base Plate Lift
When the paper feed tray is set in the machine, the set switch at the rear of the tray switches ON, and it
is detected that the tray is set.
The coupling between the shaft at the rear of the tray and the lift motor then engages, the motor rotates,
and the tray base plate is lifted. The tray base plate lifts until the paper surface pushes the pick-up roller
up, the upper limit sensor switches OFF (interrupt), and the machine enters paper feed standby mode.
When the tray is removed, the coupling is released, and the base plate moves down. The lift motor then
rotates until the coupling returns to the home position.
7. Detailed Descriptions
1160
