Product Name Code EU NA AA KOR TWN CHN

Enhanced Security HDD Option

Type M12

D3A6 -02 -02 N/A N/A N/A N/A

OCR Unit Type M13 D3AC -23 -24 -25 -25 -25 -25

Diagram

No. Item Code Remarks

1 Banner Paper Guide Tray Type

M19

D3BF-00 Common (D238/D239/D240/

D241/D242)

2 Paper Feed Unit PB3150 D694-17, -21

3 Caster Table Type M3 D178-02

Machine Codes and Peripherals Configuration
