• The PS3 firmware program is included in the preinstalled PDF firmware. In the default state,
although the PS3 firmware program is hidden in the disabled state, the function is enabled by
installing the PS3 card. (The program installed in the PS3 card is a dongle (key) for enabling the
PS3 function).
• Due to the above specification, the self-diagnosis result report shows the ROM module number /
software version of the PDF firmware at the PS location.
Error Screens During Updating
EXX shows an error code.
For error codes, refer to the following table:
Error Code List
Code Contents Solutions
20 Physical address mapping cannot
be performed.
• Switch the main power supply off and on to
try again.
• Re-insert the SD card to reboot it.
• Replace the controller board if the above
solutions do not solve the problem.
21 Insufficient memory for the
download
• Switch the main power supply off and on to
try again.
• Replace the controller board if the updating
cannot be done by switching the power off
and on.
22 Decompression of compressed
data failed.
• Switch the main power supply off and on to
try again.
• Replace the SD card used for the update.
• Replace the controller board if the above
solutions do not solve the problem.
5. System Maintenance
680

Ricoh MP C2504 Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Print Resolution	1200 x 1200 dpi
Scan Type	Flatbed, ADF
Max Scan Resolution	600 x 600 dpi
Copy Resolution	600 x 600 dpi
Max Paper Size	A3
Duplex Printing	Yes
Memory (RAM)	2 GB
Print Speed	25 ppm (A4)
Copy Speed	25 cpm (A4)
Fax Resolution	200 x 200 dpi
Paper Capacity	1200 sheets
Connectivity	USB, Ethernet, Wi-Fi
Dimensions	587 x 685 x 913 mm
Control Panel	9-inch Smart Operation Panel
