Ricoh MP C2504 - Paper Feed Motor; Transport Motor; Paper Transfer Contact and Release Motor Unit

To Next Page

To Previous Page

Paper Feed Motor

1. Power supply box (page 620)

2. Paper Feed Motor [A]

Transport Motor

1. Power supply box (page 620)

2. Transport motor [A]

Paper Transfer Contact and Release Motor Unit

1. Controller box (page 614)

4. Replacement and Adjustment

512
