Ricoh MP C2504 - Paper Path

To Next Page

To Previous Page

Paper Path

No. Description No. Description

1 SPDF DF3100 3 Booklet Finisher SR3220

2 Bridge Unit BU3070 4 Paper Feed Unit PB3220/PB3210
