• Reconnect the connector.

• Replace the sensor.

• Replace the Paper Transport IOB.

• Replace the harness.

Target Part/SP No.: PCU Motor: Black / ITB Drive Motor / SP5-804-136 (Transfer Drum Motor

K: Standard Speed)

Cause verification Problem Judgement

Turn the referenced motor OFF with OUTPUT check Drive sound heard

Turn the referenced motor ON with OUTPUT check Drive sound not heard

Solution:

• Reconnect the connector.

• Replace the motor.

• Replace the Imaging IOB.

• Replace the harness.

Checking paper jam, or paper transfer unit

Check if there is no double feeding. Fan the paper.

Check the edges of the discharge plate to see if it is deformed or

broken.

Reattach or replace the

discharge plate.

Fusing Exit Sensor : Late Jam : Cause Code 019

Target Part/SP No.:Fusing Exit Sensor / SP5-803-011 (Duplex Entrance Sensor)

Cause verification Problem Judgement

Execute an INPUT check when there is no paper at the position

of the referenced sensor.

0 :Paper detected

Execute an INPUT check when there is paper at the position of

the referenced sensor.

1: Paper not detected

Solution:

• Clean the sensor.

• Reconnect the connector.

• Replace the sensor.

Troubleshooting for Transport/Paper Feeding of the Machine

1017
