The printer system portion of the auto PDL detection function is only performed on the first 2KB of a job
and can wait up to 10 seconds for that first 2KB to arrive. As the printer is unable to detect the end of
jobs submitted over a USB/Parallel connection, it might be preferable to not wait 10 seconds if jobs of
less than 2KB are going to be printed. Enabling/disabling this waiting time is the purpose of BitSw 9-0.
BitSw 9-0=0 (default):
The printer system will not wait 10 seconds for the first 2KB of data to arrive.
BitSw 9-0=1:
The printer system will wait up to 10 seconds for the first 2KB of data to arrive.
Print Image Rotation
Printer Bit Switch Description
Bit Switch 5-6
This change the way an MFP/LP rotates PCL, PS, PDF, or RPCS print images.
BitSW 5-6=0 (default):
A uniform binding edge (short or long edge) will be applied to every page of every job. Pages will
always be rotated as if they were to be bound on that edge.
BitSW 5-6=1:
A uniform binding edge (short or long edge) will only be applied if the job is stapled, punched, or Z-
folded. Otherwise, the bound edge might differ from page to page.
Example:
A 3-page job. Page 1 has the PCL simplex command. Page 2 and 3 have the PCL duplex long-edge
bind commands.
No finishing options (staple, punch, z-fold) are used.
5. Software Configuration
680
