Ricoh MP C2504 - Drive Unit

To Next Page

To Previous Page

Drive Unit

No. Description No. Description

1 Imaging IOB 6 Transport motor

2 Development motor: CMY 7 PCU motor: Black / ITB drive motor

3 PCU motor: CMY 8 Registration motor

4 Development Solenoid 9 Fusing motor

5 Paper feed motor 10 Paper exit / Pressure release motor

Component Layout
