Ricoh MP C2504 - XPS Direct Print Option Type M19 (D3 BC-24, -25, -26); Accessory Check; Installation Procedure

To Next Page

To Previous Page

XPS Direct Print Option Type M19 (D3BC-24,

-25, -26)

Accessory Check

No. Description Qty Remarks

1 XPS Direct Print SD Card 1

Installation Procedure

• When installing more than one SD card, perform the merge operation (page 347 "SD Card Appli

Move").

1. Remove the SD card slot cover [A].

2. Installation

356
