SP No. Classification 1 Classification 2 Value
3-334-006 ID.Sens TestVal:C Vct_dif Check:Xint TM/ID sensor: C, value of [6]
3-335-001 ID.Sens TestVal:R K2: Check TM/ID sensor: R, value of [1]
3-335-002 ID.Sens TestVal:R Diffuse Corr TM/ID sensor: R, value of [2]
3-335-003 ID.Sens TestVal:R Vct_reg Check:Slope TM/ID sensor: R, value of [3]
3-335-004 ID.Sens TestVal:R Vct_reg Check:Xint TM/ID sensor: R, value of [4]
3-335-005 ID.Sens TestVal:R Vct_dif Check:Slope TM/ID sensor: R, value of [5]
3-335-006 ID.Sens TestVal:R Vct_dif Check:Xint TM/ID sensor: R, value of [6]
Replacement procedure
1. Image transfer belt unit (page 474)
2. Paper transfer roller unit (page 495)
3. Fusing unit (page 541)
4. TM/ID sensor unit [A]
• When installing the TM/ID sensor unit.
• 1. Attach the screw of the front side [B]
• 2. Attach the screw of the back side [C]
• When installed in reverse order, an SC may occur because the sensor position has shifted.
