Ricoh MP C2504 - Postscript3 Unit Type M19 (D3 BD-05, -06, -07); Accessory Check; Installation Procedure

To Next Page

To Previous Page

PostScript3 Unit Type M19 (D3BD-05, -06,

-07)

Accessory Check

No. Description Q’ty

1 SD Card 1

2 PS3 Decal 1

Installation procedure

• When installing more than one SD card, perform the merge operation (page 347 "SD Card Appli

Move").

1. Remove the SD card slot cover [A].

2. Installation

352
