Ricoh MP C2504 - Service Call 501-584; SC500 (Engine: Paper Transport 1: Paper Feed, Duplex, Transport)

To Next Page

To Previous Page

Service Call 501-584

SC500 (Engine: Paper transport 1: Paper Feed, Duplex, Transport)

SC No. Type Error Name/Error Condition/Major Cause/Solution

SC501-01 B 1st Tray Lift Error (Main Machine)

The 1st tray lift motor error detection count reaches 3 times.

(Up to 2 times, reset instruction is displayed)

• 1st tray upper limit sensor connector missing, malfunction, dirt

• 1st tray lift motor connector missing, disconnection, malfunction.

• Foreign object, such as paper scrap, is caught between the paper

feed tray and the tray lift motor.

• Paper set incorrectly

• Reload the paper.

• Remove the foreign object.

1st tray upper limit sensor, 1st tray lift motor

• Check the harness.

• Reset the connector.

• Replace

1st paper feed unit, 1st tray

• Replace

Paper transport IOB

• Replace

Service Call 501-584
