Ricoh MP C2504

To Next Page

To Previous Page

PCDU

• When installing a complete brand-new PCDU, it is not necessary to set SP3-701: New

Development Unit detection

1. Open the front cover [A].

2. Image Transfer front cover [A]

PCDU

459

RTB 24

Agitate the developer by shaking the unit
