Ricoh MP C2504 User Manual

Key Counter Bracket Type M3 (D739-09)
Accessory Check
No. Description Q’ty Remarks
- Screw: M3X8 1
- Binding Self-Tapping Screw: M4X8 3
- Clamp:LWS-1211Z 2
- Clamp:NK-3N 1
- Double Sided Tape 2
- Key Counter Plate Nut 2
- Key Counter Harness 1
Installation Procedure
• When installing this option, turn OFF the main power and unplug the power cord from the wall
socket. If installing without turning OFF the main power, an electric shock or a malfunction may
occur.
1. Hold the key counter plate nuts [A] on the inside of the key counter bracket [B] and insert
the key counter holder [C].
2. Secure the key counter holder to the bracket ( x2).
2. Installation
312
