Internal Shift Tray SH3070 (D691)
Accessory Check
No. Description Q’ty
1 Tray Cover 1
2 Lever 1 Not used for this machine
3 Sheet 2
Installation Procedure
• When installing this option, turn OFF the main power and unplug the power cord from the wall
socket. If installing without turning OFF the main power, an electric shock or a malfunction may
occur.
• The internal shift tray cannot be used together with the following peripherals:
- Side Tray Type M3 (D725)
- Internal Finisher SR 3180 (D766)
- Internal Finisher SR 3130 (D690)
- Bridge Unit BU3070 (D685)
• To use together with the "1 Bin Tray BN3110 (D3CQ)", attach the "1 Bin Tray BN3110 (D3CQ)"
first before installing the internal shift tray.
2. Installation
174
