Troubleshooting for Transport/Paper Feeding
of the Machine
Curled Paper
Make sure that the following SPs are set to their default values, and keep them at these values at all time.
• SP1-113-001 (Curl Correction): Keep at default value of 0 (OFF)
This is because printing productivity drops to about 65 to 80% when this SP is ON. It is not effective
in reducing curl on these models.
• SP1-115-xxx (Print Target Temp): Keep at default value.
This is because fusing offset may occur when the fusing temperature is reduced. This SP is not
effective for improving image quality on these models.
Solution:
Installing the tray heaters for the mainframe paper bank and optional paper banks. (page 119 "Anti-
Condensation Heater for Paper Feed Trays")
Initial Jam
If the error occurs periodically, do the following steps. If the result is as shown in the "Problem
Judgement" column, follow the solutions.
Initial Jam: Cause Code 001 / Location Code A
Target Part/SP No.: Transport Sensor (1st Feed Tray) / SP5-803-003 (Transport Sensor 1)
Cause verification Problem Judgement
Execute an INPUT check when there is no paper at the position of
the referenced sensor.
0: Paper detected
Execute an INPUT check when there is paper at the position of the
referenced sensor.
1: Paper not detected
Solution:
• Clean the sensor.
• Reconnect the connector.
• Replace the sensor.
6. Troubleshooting
1008
