Ricoh MP C2504 - Electrical Components

To Next Page

To Previous Page

(2) Electrical components

No. Description Q’ty Remarks

- TAPPING SCREW M3X6 3 Parts Number:

D2386650

Electrical parts set for Scanner and

Drum heater is common between

NA/EU

4 CLAMP 6

- HARNESS: SCANNER/PCU 1

- PCB: DHB 1

- HARNESS :DC: DHB 1

- HARNESS :AC: DHB 1

2. Installation
