Ricoh MP C2504 User Manual

Service Call 700-792
SC700 (Engine: Peripherals)
SC No. Type Error Name/Error Condition/Major Cause/Solution
SC700 SPDF DF3100 (D3B0) Error
SC700-01 D ADF bottom plate lift motor error
SC700-02 D ADF pick-up roller lift motor
SC700-04 D ADF feed motor error
SC700-05 D ADF entrance motor error
SC700-06 D ADF transport motor error
SC700-07 D ADF scanning motor error
SC700-09 D ADF exit motor error
-01
Even if the base plate motor is rotated in the base plate ascent direction,
the base plate paper feed correct position sensor does not detect.
Even if the base plate motor is rotated in the base plate descent direction,
the base plate home position sensor does not detect.
-02
Even if the pickup arm motor is rotated, the pickup arm home position
sensor does not detect.
-04, 05, 06, 07, 09
When an error notification signal is detected during the motor drive
period.
6. Troubleshooting
890
