Installation Procedure
• When installing this option, turn OFF the main power and unplug the power cord from the wall
socket. If installing without turning OFF the main power, an electric shock or a malfunction may
occur.
1. Remove the rear cover [A].
2. Remove the controller box cover [A].
Red Circle: Remove / Blue Circle: Loosen
Optional Counter Interface Unit Type M12 (B870-21)
309
