Ricoh MP C2504 - Side Tray Type M3; Accessory Check

To Next Page

To Previous Page

Side Tray Type M3 (D725)

Accessory Check

No. Description Q’ty

1 Left Extension Tray 1

2 Upper Extension Tray 1

3 Fixing Plate 1

4 Knob Screw 1

5 Tapping screw - M4 x 14 1

6 Tapping screw - M3 x 8 1

7 Bracket 1

8 Paper Support Guide 1

9 Driven Roller (Flat) 1

Side Tray Type M3 (D725)
