Ricoh MP C2504 - Feed; Transport Part

Feed / Transport Part
Items
MP C2003/C2503
/C2011
MP C6004/C5504/C4504
/C3504/C3004
MP C2004/C2504
Bypass tray / Main
machine jam code
-
The following codes are used to isolate the cause:
• JAM048: Transport Sensor Lag Jam from Bypass
Tray
• JAM051: Transport Sensor Lag Jam from 1st
Feed Tray
Main tray paper
exit
-
• Improved stacking performance after feedout by
adding resilience to the paper with the paper
exit driven roller (drum shape).
• To prevent paper jam when the paper is
delivered from the machine’s paper exit to the
internal exit peripherals, attach the paper
support guide (supplied with the peripherals).
• Replaced the paper exit driven roller to a flat
type roller to prevent jamming when paper is fed
to the internal exit peripherals.
Tray draw-in
mechanism
Not Available Available Not Available
Paper feed sensor/
Paper exit full
sensor
Not Available Available Not Available
Paper thickness
(Duplex)
52 - 169 g/m
2
52 - 256 g/m
2
52 - 169 g/m
2
Removing wrinkle
in tray
Screwed with L-shaped
sheet metal
Support component and decal are provided
User installable
7. Detailed Descriptions
1080
RTB 28
New information
