SP No. SP Name Function Description
SP1-153-003 Abnormal Noise
Confirmation: Operation
Line Speed
Line speed at the time of
rotation
0: Standard speed
1: Middle speed
2: Low speed
SP1-153-004 Abnormal Noise
Confirmation: Operation
Time
Rotates during this time. Initial
value: 60 sec.
SP1-153-005 Abnormal Noise
Confirmation: Heat
Center Target Temp
Temperature setting for
SP1-153-001 (Unit: Execute)
Do not change
SP1-153-006 Abnormal Noise
Confirmation: Heat End
Target Temp
Temperature setting for
SP1-153-001 (Unit: Execute)
SP1-153-007 Abnormal Noise
Confirmation: Press
Target Temp
Temperature setting for
SP1-153-001 (Unit: Execute)
Operation Check Procedures of the Toner Supply Motor/Toner Bottle Drive
Motor
The operation check of the toner supply motor and/or toner bottle drive motor, is performed by a forced
toner supply, not OUTPUT Check.
• Operation other than the following procedures may occur the abnormal density, toner scattering,
scumming, and cleaning failure at the image transfer unit.
1. Do [Force Tnr Supply :Exe (SP3-050-003 to 006)] for the applicable color twice. If there is
enough toner in the toner supply unit, the toner bottle drive motor will not work.
SP No. SP Name
SP3-050-003 Force Tnr Supply :Exe Execute: K
SP3-050-004 Force Tnr Supply :Exe Execute: C
SP3-050-005 Force Tnr Supply :Exe Execute: M
When Abnormal Noise Occurs
995
To Next Page
