• Replace the Paper Transport IOB.
• Replace the harness.
1st Paper Feed Tray
Replace the 1st paper feed tray. Replace the 1st paper feed tray.
"Tray 2 not set" is displayed even when the tray is set
Target Part/SP No.:Tray Set Switch (2nd Feed Tray) / SP5-803-020 (Tray 2: Set Sensor)
Cause verification Problem Judgement
Manually press the referenced switch (Done after detaching
paper feeding tray 2 from the machine.)
1: Not set
Pull out paper feed tray 2 from the machine. 0: Set
Solution:
• Reconnect the connector.
• Replace the sensor.
• Replace the Paper Transport IOB.
• Replace the harness.
2nd Paper Feed Tray
Check the 2nd tray set sensor to see if there are any
defects.
Replace the 2nd paper feed tray.
Wrong paper size displayed on the operation panel
Target Part/SP No.:Size Switch (2nd Feed Tray) / SP5-803-021 (Tray 2: Size Sensor)
Cause verification Problem Judgement
Press the 1st switch from the right on the size switch of paper
feed tray 2 when seen from the front of the machine (Done
after detaching paper feed tray 2)
Parameter other than 00000111
Press the 2nd switch from the right on the size switch of paper
feed tray 2 when seen from the front of the machine (Done
after detaching paper feed tray 2)
Parameter other than 00001011
Troubleshooting for Transport/Paper Feeding of the Machine
