15. Route the cable as shown in the following photo.

Tuck in the excess length portion of the cable in the space over the controller box.

16. Reattach the exterior covers.

Procedure for Connecting to the Operation Panel USB Slot

1. Open the right door, and then remove the small cover [A].

2. Installation

338
