Ricoh MP C2504 - Board; Switch

To Next Page

To Previous Page

Board / Switch

No. Description No. Description

1 Proximity sensor (Human detection sensor) 8 PSU (DC power)

2 Interlock switch: front cover 9 PSU (AC controller board)

3 HVP_TTS 10 BCU

4 Main power switch 11 Controller box cooling fan

5 Control board 12 IPU

6 HDD 13

Proximity sensor (Human detection sensor)

board

7 Paper transport IOB
