Laser Exposure Unit

No. Description No. Description

1 Laser optics positioning motor (Y) 5 Polygon mirror motor

2 Synchronizing detector board: M/Y-S 6 LD drive board (M/Y)

3 Laser optics positioning motor (M) 7 LD drive board (Bk/C)

4 Laser optics positioning motor (C) 8 Synchronizing detector board: Bk/C-S
