Anti-Condensation Heater for Paper Feed
Trays
• Unplug the machine power cord before starting the following procedure.
• Do the following procedure not to damage any harnesses.
• Check that harnesses are not damaged or pinched after installation.
Accessory Check
Anti-Condensation Heater (Service Option) for Main Machine
No. Description Q’ty Remarks
1 Tray heater 1 Heater and harness
Parts Number:
• NA (120V): D2386630
• EU/AA (220/240V): D2386640
2 Tapping screw: M3 X 8 2
3 PCB: DHB 1 Electrical components
Parts Number:
• NA (120V): D2386661, *D2386660
• EU/AA (220/240V): D2386662,
*D2386660
4 Harness for tray 1
5 Harness for DC 1
6 Harness for AC 1
7 Tapping screw: M3 X 6 3
*: Old parts number
Anti-Condensation Heater (Service Option) for Optional Paper Feed Unit
No. Description Q’ty Remarks
1 Tray heater 1 Heater and harness
Parts Number:
• NA (120V): D6931117
• EU/AA (220/240V): D6931127
Those parts number is common with MP C2003/
C2503.
2 Harness 1
3 Spring screw:M4 X 10 3
Anti-Condensation Heater for Paper Feed Trays
119
RTB 36
Additional information
