Adjustment before Replacing the Fusing Sleeve Belt Unit
Before replacing the fusing sleeve belt unit, set SP3-701-116 to "1" and switch the power OFF. Then
replace the fusing sleeve belt unit and switch the power ON.
SP3-701 (Manual New Unit Set)
This SP is the new unit detection flag.
0: new unit detection flag OFF, 1: new unit detection flag ON
Item SP
Fusing sleeve belt unit SP3-701-116
Replacement
1. Fusing upper cover (page 544)
2. Fusing lower cover (page 545)
3. Left frame [A]
4. Exit guide plate (left) unit [A]
Fusing Unit
547
