5,180 - 5,240 MHz (36, 40, 44 and 48 channels)
(default: 11)
• In some countries, only the following channels are available: 2,412 - 2,462 MHz (1 - 11
channels)
• For mainly North America
2,412 – 2,462 MHz (1 - 11 channels)
5,180 – 5,240 MHz (36, 40, 44 and 48 channels)
(default: 11)
7. Set the "Security Method" to specify the encryption of the Wireless LAN.
• The "WEP" (Wired Equivalent Privacy) setting is designed to protect wireless data
transmission. The same WEP key is required on the receiving side in order to unlock encoded
data. There are 64 bit and 128 bit WEP keys.
• Range of Allowed Settings:
64 bit: 10 characters
128 bit: 26 characters
• Specify "WPA2" when "Communication Mode" is set to "Infrastructure Mode". Set the "WPA2
Authent. Method".
• WPA2 Authent. Method:
Select either "WPA2-PSK" or "WPA2".
If you select "WPA2-PSK", enter the pre-shared key (PSK) of 8-63 characters in ASCII
code.
When "WPA2" is selected, authentication settings and certificate installation settings are
required.
8. Press "Wireless LAN Signal" to check the machine's radio wave status using the operation
panel.
• Press "Restore Factory Defaults" to initialize the wireless LAN settings.
SP Mode Settings for IEEE 802.11 Wireless LAN
The following SP commands and UP modes can be set for IEEE 802.11
SP No. Name Function
SP5-840-006 Channel MAX Sets the maximum range of the channel settings for the country.
IEEE 802.11agn Interface Unit Type M19 (D3BR-01)
293
