Ricoh MP C2504 - When Changing the FFC

4. Remove the double-sided tape.
When reattaching the same part, apply a double-sided tape again.
5. Rear cover (page 411)
6. Controller box cover (page 600)
7. While pressing the lock release lever, pull out the FFC [A].
When Changing the FFC
When changing the FFC, stick the Mylar [A] to the new FFC.
4. Replacement and Adjustment
448
