Ricoh MP C2504 - Scanner Motor

To Next Page

To Previous Page

• When attaching the resin cover, insert its tip under the metal frame.

Scanner Motor

1. Scanner upper cover (page 434)

2. Rear cover (page 411)

3. Grounding plate [A]

Scanner Unit

443
