• Imaging IOB malfunction
6. Laser optics positioning motor in laser unit defective
• Connector/ harness disconnected
• Motor malfunction
• Imaging IOB malfunction
Solutions
As SC285-02 is a logging SC (SC Type C), it is not displayed at once when an error occurs. Though the
equipment can be operated, check the SC history and perform a recovery operation if the SC has
occurred.
Troubleshooting for SC Errors
967
