Toner Supply / Waste Toner Bottle
No. Description No. Description
1 ID chip contact board (Y) 10 Toner end sensor (Y)
2 Toner bottle drive motor (Y) 11 Toner supply motor (M)
3 ID chip contact board (M) 12 Toner end sensor (M)
4 Toner bottle drive motor (M) 13 Toner supply motor (C)
5 ID chip contact board (C) 14 Toner end sensor (C)
6 Toner bottle drive motor (C) 15 Toner end sensor (Bk)
7 ID chip contact board (Bk) 16 Toner supply motor (Bk)
8 Toner bottle drive motor (Bk) 17 Waste toner bottle full sensor
7. Detailed Descriptions
1090
